. The MODEL VT-300 Miniature Vane Thermo-Anemometer measures air velocity, air volume, temperature, and humidity inside air ducts. This meter includes a telescoping vane probe that is only 0.7' (18 mm) in diameter that allows duct traverse measurements up to 20' ducts. User-selectable units include ft/min, m/s, knots, mph, and km/hr. The vane probe has a built-in sensor to record temperature in °F or °C, as well as humidity in%RH.
There are three modes which include viewing data in real time, manual recording, and automatic recording. Model VT-300 can store measurements that can later be transferred to a PC via RS-232 communication. The vane probe is detachable for easy replacement, if necessary. Each unit is supplied with a hard carrying case, batteries, logging software CD, USB to RS-232 cable and instruction manual. Product Applications. Building commissioning. Building HVAC test and balance.
Critical environment testing. Industrial process verification. Instrumentation validation. Shipping Information All shipping times are dependent on product availability at time of shipment. Although we make every effort to ensure a continuous supply of our products, occasional circumstances may force us to temporarily run out of a product, or have shipping delays.
Should this occur, customers will be notified soon after placement of any orders for such products and, if applicable, items will be put on backorder. For orders requiring expedited shipment, our customer service team can be contacted to confirm product availability Sort by Model Description VT-300. Miniature Vane Thermo-Anemometer Specifications AIR VELOCITY Range: 98.4 to 3937 ft/min (0.5 to 20 m/s). Accuracy: ±3% of reading + 0.2 m/s. Resolution: 0.1 m/s. Response Time: 1 s. TEMPERATURE Range: -4 to 140°F (-20 to 60°C).
Accuracy: ±1°F (±0.6°C) from -4 to 122°F (-20 to 50°C); ±2.2°F (±1.2°C) from 122 to 140°F (50 to 60°C). Resolution: 0.1°F (0.1°C). Response Time: 60 s (typ). RELATIVE HUMIDITY Range: 0.1 to 99.9% RH.
Accuracy: ±3% RH at 25°C (10 to 90% RH); ±5% RH (0.1 to 10% RH, 90 to 99.9% RH). Resolution: 0.1% RH. Response Time: 60 s (typ). AIR VOLUME Range: 0 to 99,999 (CFM or m3/s). Resolution: 0.1 (0 to 9999.9) or 1 (10,000 to 99,999).
WET BULB Range: -7.6 to 158°F (-22 to 70°C). Resolution: 0.1°F (0.1°C). METER Temperature Limits: Operating: 32 to 122°F (0 to 50°C); Storage: -4 to 122°F (-20 to 50°C).
T300 Manual
Humidity Limits: Operating.
