CCNA Exploration 4.0.5.0 Routing Protocols and Concepts Student Lab Manual This document is exclusive property of Cisco Systems, Inc. Permission is granted to print and copy this document for non-commercial distribution and exclusive use by instructors in the CCNA Exploration: Routing Protocols and Concepts course as part of an official Cisco Networking Academy Program. Lab 1.5.1: Cabling a Network and Basic Router Configuration Topology Diagram Addressing Table Device Interface IP Address Subnet Mask Default Gateway Fa0/0 192.168.1.1 255.255.255.0 N/A R1 S0/0/0 192.168.2.1 255.255.255.0 N/A Fa0/0 192.168.3.1 255.255.255.0 N/A R2 S0/0/0 192.168.2.2 255.255.255.0 N/A PC1 N/A 192.168.1.10 255.255.255.0 192.168.1.1 PC2 N/A 192.168.3.10 255.255.255.0 192.168.3.1 Learning Objectives Upon completion of this lab, you will be able to: Cable devices and establish console connections. Erase and reload the routers. Perform basic IOS command line interface operations. Perform basic router configuration. Verify and test configurations using show commands, ping and traceroute.

1. Biology Lab Manual
2. Physics Lab Manual

Create a startup configuration file. Reload a startup configuration file. Install a terminal emulation program. Scenario In this lab activity, you will review previously learned skills including cabling devices, establishing a console connection, and basic IOS command line interface operation and configuration commands. You will also learn to save configuration files and capture your configurations to a text file.

Biology Lab Manual

The skills presented in this lab are essential to completing the rest of the labs in this course. However, you may substitute the shorter version, Lab 1.5.2: Basic Router Configuration, if your instructor determines that you are proficient in the essential skills reviewed in this lab. All contents are Copyright © 1992–2007 Cisco Systems, Inc. All rights reserved. This document is Cisco Public Information. Page 1 of 28 CCNA Exploration Routing Protocols and Concepts: Introduction to Routing and Packet Forwarding Lab 1.5.1: Cabling a Network and Basic Router Configuration Task 1: Cable the Ethernet Links of the Network.

Cable the Ethernet links for a network that is similar to the one in the Topology Diagram. The output used in this lab is from Cisco 1841 routers. But you can use any current router in your lab as long as it has the required interfaces as shown in the topology.

A simple way to identify the available interfaces on a router is by entering the show ip interface brief command. Which of the devices in the Topology Diagram require an Ethernet cable between them? Step 1: Connect the R1 Router to the S1 Switch. Use a straight-through Ethernet cable to connect the FastEthernet 0/0 interface of the R1 router to the FastEthernet 0/1 interface on the S1 switch. What color is the link status light next to the FastEthernet 0/0 interface on R1? What color is the link status light next to the FastEthernet 0/1 interface on S1?

Step 2: Connect PC1 to the S1 Switch. Use a straight-through Ethernet cable to connect the network interface card (NIC) of PC1 to the FastEthernet 0/2 Interface of the S1 switch. What color is the link status light next to the NIC interface on PC1?

What color is the link status light next to the FastEthernet 0/2 interface on S1? If the link status lights are not green, wait a few moments for the link between the two devices to become established. If the lights do not turn green after a few moments, check that you are using a straight- through Ethernet cable and that the power is on for the S1 switch and PC1. Step 3: Connect PC2 to the R2 Router.

Use a crossover Ethernet cable to connect the FastEthernet 0/0 interface of the R2 router to the NIC of PC2. Because there is no switch between PC2 and the R2 router, a crossover cable is required for a direct link between the PC and the router. What color is the link status light next to the NIC interface on PC2? What color is the link status light next to the FastEthernet 0/0 interface on R2? Task 2: Cable the Serial Link between the R1 and R2 Routers. In a real-world WAN connection, the customer premises equipment (CPE), which is often a router, is the data terminal equipment (DTE). This equipment is connected to the service provider through a data circuit-terminating equipment (DCE) device, which is commonly a modem or channel service unit (CSU)/ data service unit (DSU).
